Unit Price |
Unstated |
Number of Units |
1 |
Manufacturer | M.T.A. S.p.A. |
Model | TAE EVO 121-SS |
Cooling System |  |
External Cooling | Air Cooled |
Pump type/Model | Centrifugal, Stainless Steel (water side) |
Cooling Capacity | 41,869 W (142,800 BTU/hr) |
Minimum Temperature | -5 ºC (23 ºF, 268.00 ºK) |
Heat/Cool Controls |  |
Control Type | Digital Setpoint |
Overtemperature Protection | YES |
Min Flow | 16 GPM (60.81 l/m) |
Max Flow | 66 GPM (250.84 l/m) |
Minimum Pressure | 56.000 PSI (3,861.37 mbar, 386,136.80 Pa) |
Maximum Pressure | 84.000 PSI (5,792.05 mbar, 579,205.20 Pa) |
Capacity/Liquid | 242.27 L (64.00 gal) |
Other Information | Scroll type refrigeration compressor -- R407C refrigerant
Input Voltage: 480/277V, |
Power Requirements | Other V
43.0 A
60 Hz
3 Phase
|
CE Marked | YES |
Year of Manufacture | 2011 |
Exterior Dimensions |  |
Width | 30.000 in (76.2 cm) |
Depth | 73.000 in (185.4 cm) |
Height | 57.000 in (144.8 cm) |
Weight | 1,415 lb (642 kg) |
