FULL DESCRIPTION of Item 172335

in High Voltage Power Supplies
Deal directly with Owner:  Capovani Brothers Inc. of Scotia, New York

Item ID: 172335

Offered 4 Offered at $ 1,999.00 (each)


GLASSMAN HIGH VOLTAGE POWER SUPPLY, 5 kV

High Voltage Power Supply Positive or Negative Polarity


Location: Scotia, New York
Unit Price $ 1,999.00 (each)
Number of Units 4
Manufacturer Glassman
Model PS/FC05P24 or PS/FC05N24
Maximum Output Voltage 5.0 kV
Maximum Output Current 24.0 mA
Bipolar No
Panel Meters Digital
Ripple <0.02% RMS of rated voltage +300mV at full load
Regulation Better than 0.1%
Interface I/O Port
External Cooling Air Cooled
Other Information


Positive or Negative Polarity, request when ordering (not user configurable)
Can be configured for 230VAC input, request when ordering (not user configurable)
SHV output connector, high voltage cable is NOT included
RS232 option is NOT included

We will not honor our 90 day warranty if this power supply will be used for the spark gap applications



Extended Description  Details at FC_SeriesSpecs.pdf
Power Requirements 115 V     48-440 Hz     1 Phase
Condition Excellent
Exterior Dimensions
  Width 19.000  in  (48.3 cm)
  Depth 20.000  in  (50.8 cm)
  Height 1.720  in  (4.4 cm)
Weight 12  lb  (5 kg)

OFFERED BY:
(click name below to visit its website directly)
Capovani Brothers Inc.
Scotia , New York
1.518.346.8347

Shipping & Handling:

Unless otherwise stated, all items will be fully tested and sold with our standard ninety day warranty, which is described in our terms and conditions.
Our standard procedure is to service the equipment as orders are placed. Lead times can vary depending on the item.
Domestic and International shipments: Ex Works, Scotia, NY. All freight cost estimates are for dock to dock service only.
Any additional services, i.e. lift-gate, inside or residential delivery, must be requested at the time of sale and will be billed accordingly.
CBI is not responsible for any damage incurred during shipment. It is the buyer's responsibility to inspect packages for damage and to note any damage on bill of lading.
Please feel free to call us with any questions. (Phone: 518.346.8347, Fax: 518.381.9578).

Payment:

Minimum order of $50 required.
We offer terms of net 30 days to all companies that have established credit with Capovani Brothers Inc. and have paid within terms.
All federal, state, local governments and their agencies, as well as institutions of higher learning automatically receive terms.
All other sales, including foreign sales, are prepayment only.
MasterCard, VISA, Discover and AMEX are accepted at sellers discretion.

Domestic Terms and Conditions

International Terms and Conditions




Deal directly with Owner:  Capovani Brothers Inc. of Scotia, New York
