Unit Price |
Unstated |
Number of Units |
1 |
Manufacturer | Leica |
Model | POLYLITE 88 |
Microscope Type | Upright |
Microscope Configuration | Brightfield & Darkfield |
Illumination Type | Reflected Light |
Binocular Angle | Variable |
Eyepieces |  |
Model | WPK |
Magnification | 10 X |
Field Number | 20 mm |
Focusing | YES |
Wafer Size | 200.00 mm (7.87 in) |
Magnification Changer | 1.0,2.0 |
Motorized Nosepiece | YES |
Multiple Objectives Models | PLAN FLUOR LWD 5X/0.10 EPI PLAN FLUOR LWD 10X/0.20 EPI PLAN FLUOR XLWD 20X/0.40 EPI PLAN FLUOR 50X/0.80 EPI PLAN FLUOR 100X/0.90 EPI |
Infinity Corrected Objectives | YES |
Illumination Power | Volts: 14
Watts: 85
|
Power Supply Included | YES |
Wafer Stage/Loader |  |
Manufacturer | Microvision Corp |
Model | MVT 1080 |
Wafer Size | 200.00 mm (7.87 in) |
Stage Type | Coaxial X-Y |
Stage Area | Length: 204 mm (8.031 in)
Width: 204.0 mm (8.031 in)
|
Camera |  |
Type | None |
Accessories | Trinocular with Beam Splitter (Photo tube not included) |
Other Information | Adustable Aperture Diaphragm and Field Diaphragm |
Power Requirements | 120/240 V
47-63 Hz
1 Phase
|
Condition | Excellent |
Exterior Dimensions |  |
Width | 16.000 in (40.6 cm) |
Depth | 30.000 in (76.2 cm) |
Height | 19.000 in (48.3 cm) |
Weight | 162 lb (73 kg) |
