Unit Price |
Unstated |
Number of Units |
2 |
Manufacturer | Leica |
Model | Polylite 88 |
Microscope Configuration | Brightfield & Darkfield |
Illumination Type | Reflected Light |
Binocular Angle | Variable |
Eyepieces |  |
Model | WPK |
Magnification | 10 X |
Field Number | 20 mm |
Focusing | YES |
Magnification Changer | 1.0, 2.0 or 1.0, 2.5 |
Motorized Nosepiece | YES |
Multiple Objectives Models | Plan Fluor LWD 5X/0.10 Epi Plan Fluor LWD 10X/0.20 Epi Plan Fluor XLWD 20X/0.40 Epi Plan Fluor LWD 50X/0.60 Epi Plan Fluor LWD 100X/0.70 Epi |
Infinity Corrected Objectives | YES |
Illumination Power | Volts: 14
Watts: 85
|
Power Supply Included | YES |
Stage Type | Coaxial X-Y |
X-Y-Z Stage Travel | X: 203 mm (7.992 in)
Y : 203 mm (7.992 in)
|
Accessories | Filter Slide: Grey and Yellow Triple Illumination Module Trinocular with Beam Splitter (Photo tube not included) |
Other Information | Adustable Aperture Diaphragm and Field Diaphragm |
Power Requirements | 120/220 V
50/60 Hz
1 Phase
|
Exterior Dimensions |  |
Width | 29.000 in (73.7 cm) |
Depth | 18.000 in (45.7 cm) |
Height | 20.000 in (50.8 cm) |
Weight | 98 lb (44 kg) |
